Volume of a rock by water displacement

An example figure from the Volume by Displacement generator.

Two 100 mL graduated cylinders: water at 50.0 mL before, and at 63.5 mL after a rock is added — Two 100 mL graduated cylinders side by side, labeled Before and After. The first holds water at 50.0 mL; in the second a rock rests on the bottom and the water has risen to 63.5 mL. The rock’s volume is the difference, 13.5 mL.

Edit this figure Download PNG

Editing opens it in Volume by Displacement with these settings, to change anything and copy or download your own.

Answer key

Before: 50.0 mL
After: 63.5 mL
Object: 13.5 mL
